| Power Supplier | Three Phase |
| Voltage | 415 V/Ac |
| Absorbed Power | 10 - 50 Kw |
| Capacity of Crucible | 10 - 60 Kg |
| Maximum Temperature | 1150 |
| Melting Time | 15 - 40 Minutes |
| Temperature Measurement | K Type |
| Cooling Water Temperature | 30 |
| Water Pressure | 4 Bar |
| Maximum Water Flow | 4 Lit/Min |
| Dimension | (mm) L x B x H |
|---|---|
| Furnace Unit | 800 X 600 X 1130 |
| Chilling Unit | 840 X 590 X 1050 |
| Weight | (kg - Approx) |
|---|---|
| Furnace Unit | 79net |
| Chilling Unit | 131net |
| Advanced induction heating technology for rapid and uniform gold melting |
| Heavy-duty construction suitable for continuous industrial use |
| Digital temperature controller & display for precise melting control |
| High energy efficiency with optimized power consumption |
| Fast melting cycle with minimal oxidation and metal loss |
| Compatible with high-quality graphite crucibles |
| Enhanced safety systems for operator and equipment protection |
| Low maintenance design for long service life |
| Consistent performance for high-volume production |
| Reduced melting time and operational cost |
| Clean, smokeless, and noise-free operation |
| Reliable output with professional-grade results |
